STM8摇头频闪
防水亮化系列
XD-BF380

信息参数

[型        号]:XD-BF380

[产品尺寸]:378x326x547mm


[发布时间]:2018-05-03 16:54:21

咨询热线400-631-3159

性能参数 易耗件 产品配件 产品包装 产品效果 应用场所 产品视频


Product Basic Information
Product Name: Waterproof Beam Light
Type: XD-BF380
Size: 400x320x670mm
Weight: 25kg
Color: Black
IP Rating: IP65

Technical parameters of products
Input Voltage: 220V AC ,50/60Hz
Rated Power: 450W
Output Voltage: V1:36V;V2:12V;V3:380V
Maximum Output Power: 600W
Output Power of Light Source: 380W

Optical System
Light Source: Philips Light Source
Lighting Inverter: Philips original lighting Inverter
Type of Light Source: HPML
Beam Angle: 0-10°
Illumination: 10m Testing Distance: 500,000 lux

Control System
Control Mode: DMX512/ Manual Mode/ Sound control/ Self-propelled
Chanel: Double Chanel Mode, 16/20CH
Calibration Mode: Automatically Reset Calibration
Cooling Mode: Wind circulating cooling system
Special Settings: XY axis can be set to reverse

Brief Introduction to Functions
Colour: 14 colours + white
Dimming: 0-100% linear dimming
Strobe: 0-20 times/s, linearly adjustable
Gobo Wheel: 17 geometric gobos
Prism: Double Prisms Combination, 3+8 prisms, can be customized two other prisms
Atomization: Softening light, can be used for embellishment dyeing
Focusing: from far to near, linear focusing
X-axis: Horizontal displacement 540 degrees, with fine-tuning function
Y-axis: vertical displacement 270 degrees, with fine-tuning function
Reset Calibration: Most operating faults can be calibrated by reset function.
Bulb Control: Programmable Control of Bulb Extinguishing and Lighting
XY Speed: 100-0% Linear Adjustment of XY Axis Speed




1: waterproof power cord
2: Waterproof signal line


1: paper loaded (with pearl cotton)
2: Customized air box
